Model

Brand:ECS

Model;A785GM-AD3(1.0)

Supported CPU

CPU Socket Type:AM3

CPU Type:Phenom II / Athlon II / Sempron 100 Series
Supports CPU up to 95W TDP only

FSB:2600MHz Hyper Transport (5200 MT/s)

Chipsets

North Bridge:AMD 785G

South Bridge:AMD SB710

Memory

Number of Memory Slots:4×240pin

Memory Standard:DDR3 1600(OC)/1333/1066/800

Maximum Memory Supported:16GB

Channel Supported:Dual Channel

Expansion Slots

PCI Express 2.0 x16:1

PCI Express x1:2

PCI Slots:3

Storage Devices

PATA:1 x ATA133 2 Dev. Max

SATA 3Gb/s:5

SATA RAID:0/1/10

Onboard Video

Onboard Video Chipset:ATI Radeon HD 4200

Onboard Audio

Audio Chipset:Realtek ALC888S

Audio Channels:8 Channels

Onboard LAN

LAN Chipset:Realtek 8111DL

Max LAN Speed:10/100/1000Mbps

Rear Panel Ports

PS/2;2

Video Ports:D-Sub + DVI

USB 1.1/2.0:6 x USB 2.0

Esata:1 x eSATA 3Gb/s

S/PDIF Out:1 x Optical

Audio Ports:5 Ports

Onboard USB

Onboard USB:3 x USB 2.0 headers support additional 6 USB ports

Physical Spec

Form Factor:ATX

Dimensions:12" x 8.6"

Power Pin:24 Pin

مادربورد الایت گروپ A785GM-AD3
