AMD FM1 socket CPU , Quad-Core CPU; Up to 4 "Husky" CPU Cores
AMD A75 (Hudson D3)Chipset
Dual channel DDR3 1866/1600/1333 x 4 DIMMs, Max. 64GB
1* PCIe x16, 2* PCIe x1, 3* PCI
6* SATAIII, SATA RAID 0, 1, 10
Supports 7.1 channel audio, Gbe Lan

Processor	AMD FM1 socket CPU , Quad-Core CPU; Up to 4 "Husky" CPU Cores
Chipset	AMD A75 FCH (Hudson D3) Chipset
Front Side Bus
Memory	Dual channel DDR3 1866/1600/1333 x 4 DIMMs, Max. 64GB
VGA on Die
Expansion Slots	1* PCIe x16, 2* PCIe x1,3* PCI
IDE	N/A
Serial ATA(SATA)/RAID	6* SATAIII ,SATA RAID 0,1,10
Audio	Supports 7.1 channel audio
LAN	Supports Gbe Lan
IEEE1394	N/A
Back Panel I/O Ports	1x PS/2 keyboard port 1x VGA port 1x DVI port 1x audio jack supports 6 jacks 1x S/PDIF out port(optical) 6x USB 2.0 ports 2x USB 3.0 ports 1x RJ45 Lan port
Internal I/O Connectors	1x ATX 24-Pin power connector 1x 4-pin ATX 12V power connector 3x 4-pin CPU / System Fan connector 1x CD-in connector 1x Speaker header 6x Serial ATA connectors 2x USB 2.0 headers 1x USB 3.0 headers 1x TPM/TCM header 1x Intrusion Alarm header 1x Buzzer (reserved) 1x COM header 1x Front Panel header 1x S/PDIF out header(reserved) 1x Front Audio header 1x IR/CIR header (default IR)
BIOS Features	16Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI 2.0
Support CD	Drivers, Adobe Reader, SuperUtilities, Norton Internet Security
Standards/Manageability	Supports up to 10 USB 2.0 ports+4USB 3.0
Special Features
Form Factor	ATX formfactor 12 inch x 9.0 inch

The A75A Support FM1 socket CPU.offers enhanced connectivity and entertainment capability, backed-up by high-performance features and components. Based on the AMD®A75( Hudson D3) chipset with an advanced DirectX 11 graphics engine and AMD UVD 3.0 technology. UVD supports Blue-Ray and HD-DVD content, whilst offloading power and processor-intensive video decoding from the CPU to the graphics core.Supporting AMD the Llano APU processors with UMI technology, and supports Dual DDR3 1866MHz memory for better overall system performance. Support AMD Radeon™HD6xxx graphics and Dual Graphics capable technology .The A75A support AMD Turbo
