Overview

The 10“ woofer and the 1“ driver with rotatable 90°x70° constant directivity horn, can handle up to 600 Watt and are able to put out up to 125dB spl.

ARENA 10 offers a superb sound quality and can be used as a standard fullrange enclosure (at reduced low frequency reproduction) or in combination with the ARENA SW15 subwoofer.

Due to the extensive configuration and sound performance the ARENA 10 is one of a kind.Testo prova MINI BOX Questa è una prova di pubblicazione ( per capire le lunghezze dei contenuti ) • 8 modules (2 m array) connected to one 16A phase place just 125 kg load on the pick-point • Fully powered units, freely scalable to setups of any size • Lossless signal path with no need for speaker cables • None of the impedance and amp channel availability concerns associated with passive models • Sequentially configurable array segments • Digital controller (DSP) onboard for utmost operating safety

Tech specs

Technical Data

Speaker Type: 2-Way Passive Speaker

Acoustical data

Nominal Power Rating: 300 W/RMS

Program Power Rating: 600 W

Impedance: 8 Ohms

Frequency Response [+/- 3dB]: 95 - 19.000 Hz

Max SPL: 125 dB

HF: 1 “

Driver Protection: PTC

Directivity: 90x70 °

Horn: CD Horn

Rotatable Horn: YES

Crossover Frequency (passive): 2100 Hz

LF: 10 “

Voice Coil LF: 2 “

Input

Signal Input: 1x Speakon (Pin 1+=+) (Pin 1-=-)

Signal Output: 1x Speakon (Pin 1+=+) (Pin 1-=-)

Mechanics

Housing: Multiplex birch plywood

Pole mount:: 36mm

Angles Up: Monitor use 45 °

Rigging Points: 12 x M8

Width: 321 mm (12.84 in)

Height: 508 mm (20.32 in)

Depth: 320 mm (12.8 in)

Weight: 12.2 kg (26.9 lbs)
