Intel® Core™2 Quad, Core™2 Duo, Pentium® Dual-Core, Pentium® D, Pentium® 4, Celeron® processors, Socket T (LGA775)
Supports Intel® 45nm Multi-Core processors
1600(oc**)/1333/1066/800/533(** )MHz (FSB)
Dual channel DDR2 800/667/533 x 2 DIMMs, Max 4GB
1 x PCIe x16, 1x PCIe x1, 2 x PCI
ATA100 x 1 , SATAII x 4
5.1 channel, Realtek® ALC662
10/100M Lan, Realtek® RTL8101E

8 USB 2.0 ports

Processor:	Intel® Core™2 Quad, Core™2 Duo, Pentium® Dual-Core, Celeron Dual-core, Celeron® processors, Socket T (LGA775) Supports Intel® 45nm Multi-Core processors
Chipset:	Intel® G31 + ICH7
Front Side Bus:	1600(oc) / 1333 / 1066 / 800 /533()MHz (FSB)
Memory:	Dual channel DDR2 800/667/533 x 2 DIMMs, Max 4GB
VGA on Die:	Integrated
Expansion Slots:	1 x PCIe x16, 1 x PCIe x1, 2 x PCI
IDE:	ATA 100 x 1
Serial ATA(SATA)/RAID:	SATAII x 4
Audio:	5.1 channel, Realtek® ALC662
LAN:	10/100M Lan ,Realtek® RTL8101E
IEEE1394:	N/A
Back Panel I/O Ports:	1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x Serial port 1 x Parallel port 1 x Audio jack supports 3 jacks 1 x VGA port 4 x USB 2.0 ports 1 x RJ45 LAN port
Internal I/O Connectors:	1 x ATX 24-Pin power connector 1 x 4-Pin ATX 12V power connector 2 x 4-Pin CPU/System fan connectors 1 x CD-in connector 1 x Front Audio header 1 x ATA100 connector 1 x Floppy connector 1 x CIR header 1 x Front Panel connector 2 x USB 2.0 connectors support additional 4 ports 4 x SATAII connectors 1 x TPM header 1 x S/PDIF Out header 1 x Speaker header 1 x Intrusion Alarm header
BIOS Features:	8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI
Support CD:	WHQL Drivers, Adobe Reader 7.07, Direct x 9.0, Norton 2006
Standards/Manageability:	PCI 2.3, USB2.0, DMI 2.5
Special Features:	FSB 1600 Achieved by overclockingy Please refer to our CPU support list for detailed 533 FSB CPU support
Form Factor:	Micro ATX (9.6” x 8.0”)
