- AMD Phenom™, Athlon™ 64x2, Athlon™ 64, Sempron™ processors, Socket AM3 / AM2+ and AM2.
- Supports Socket AM3/AM2+ with HT3.0 interface
- 5.2 GT/s HyperTransport™
- Dual channel DDR2 1066/800/667/533 x 2 DIMMs, Max 4GB
- 1* PCIe 2.0 x16, 2* PCIe 2.0 x1, 3* PCI
- 1* ATA 133, 4* SATAII
- 5.1 channel HD Audio, Realtek® ALC662
- Gigabit LAN, Realtek® RTL8111B / RTL8111D
- 8 USB 2.0 ports

Processor:	AMD Phenom™, Athlon™ 64x2, Athlon™ 64, Sempron™ processors, Socket AM3 / AM2+ and AM2.
Chipset:	nForce 720D
Front Side Bus:	5.2 GT/s HyperTransport™
Memory:	Dual channel DDR2 1066/800/667/533 x 2 DIMMs, Max. 4GB
VGA on Die:	Discreted
Expansion Slots:	1* PCIe 2.0 x16, 2* PCIe 2.0 x1, 3* PCI
IDE:	1* ATA 133
Serial ATA(SATA)/RAID:	4* SATAII w / RAID 0, 1, 10, 5
Audio:	5.1 channel HD Audio by Realtek® ALC662
LAN:	Gigabit LAN by Realtek® RTL8111B / RTL8111D
IEEE1394:	N/A
Back Panel I/O Ports:	1 x PS/2 keyboard port 1 x PS/2 mouse port 1 x Parallel Port 1 x Serial Port 1 x Audio jack supports 6 jacks 4 x USB 2.0 ports 1 x RJ45 LAN port
Internal I/O Connectors:	1 x ATX 24-Pin power connector 1 x 4-pin ATX 12V power connector 2 x 4-pin CPU / System FAN connectors 1 x CD-in connector 1 x Front Audio Header 1 x Floppy disk drive connector 1 x S/PDIF Out header 1 x IrDA hearder 2 x USB 2.0 headers support additional 4 ports 4 x Serial ATAII connectors 1 x ATA133 IDE connector 2 x USB Power headers 1 x Frant Panel header 1 x Intrusion Alarm header 1 x Speaker hearder
BIOS Features:	8Mb flash EEPROM w/ LAN boot PnP, ACPI, WfM, DMI 2.0
Support CD:	Drivers, DirectX, Adobe Reader, SuperUtilities, Norton Internet Security
Standards/Manageability:	PCI 2.3, USB2.0, DMI 2.5
Form Factor:	ATX ( 12" x 7.6")
